Condition:New
Model:BT-7803
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
Description:
* PWM function,intelligent IR illumination & power consumption is variable,dependant the zoom factor
* IR distance 140M; Multiple languages for OSD menu, English, Spanish etc.;
* Support ambient light detection,IR Illumination On 1-15 grade selectable;
* Dome ID, baud rate, communication protocol can be set via the controller;
* Supported Protocols : Pelco-D/P; Others on special request;
* 7",Total metal body construction, waterproof IP 66;
* Optional IP module (built in provision);
* Optional , 4 Alarm inputs and 2 alarm outputs.
| Specifications: | ||||||||
| Horizontal Rotation Speed | 100¡ã/s | |||||||
| Horizontal Rotation Range | 360¡ã | |||||||
| Tilt Rotation Speed | 50º/s | |||||||
| Tilt Rotation Range | 94¡ã | |||||||
| Auto Flip | Horizontal 180¡ã,Vertical 90¡ã | |||||||
| Auto control IR LED | PWM | |||||||
| A-B Scan | User programmable | |||||||
| A-B Scan Speed | 15-64 speed setting available | |||||||
| Dwell Preset | 2-60s interval | |||||||
| Preset Points | 220 | |||||||
| Go to Preset Speed | 80¡ã/s | |||||||
| Guard Tours | 3 groups | |||||||
| Guard Points | Max.16 points, dwell time user selectable | |||||||
| Home Pos Time | 1-60mins available | |||||||
| PWR on Action | Memory as power off/360¡ã scan/A-B scan/Preset cruise1-3 | |||||||
| Communication Protocol | Pelco-D,Pelco-P | |||||||
| Communication | RS485 | |||||||
| Baud Rate | 1200/2400/4800/9600bps | |||||||
| Operating Temperature | Indoor:0¡ã~ +40¡ã Outdoor: -40¡ã~ +60¡ã | |||||||
| Operating humidity | ¡Ü95% Non Condensing | |||||||
| Heater & Blower | Auto temperature control | |||||||
| Power | AC/DC15-28V ¡Ü3A | |||||||
| IR Illumination Distance | 140M | |||||||
| Power Consumption | 20W | |||||||
| Lightning protection | transient voltage 3000V | |||||||
| Compatible camara | SONY,LG,CNB,SAMSUMG,HITACHI | |||||||
| LED Angle of Illumination | Ø20=8,Ø16=5 | |||||||
