Condition:New
Model:MTV-64G2DH or MTV-64G2DN choose
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
lightspot:
* 1/4" COLOR
* 480 TV LINES
* OSD CONTROL PANEL
* 22X MOTOR ZOOM. AUTO FOCUS. AUTO IRIS
* FREEZE FUNCTION. CROSS LINE
* ZERO COLOR ROLLING
| ITEM: | DESCRIPTION: | ||
| Model No. | MTV-64G2DHN | MTV-64G2DHP | |
| TV System | NTSC | PAL | |
| Picture Element: | 811(H) X 508(V) | 795(H) X 596(V) | |
| Scanning System | 525 lines, 60 fields/sec | 625 lines, 50 fields/sec | |
| Sync system: | Internal / VD-Lock | ||
| Minimum Illumination: | Typical | 1.5 Lux of F1.2 | |
| Star Light Mode | 0.03Lux of F1.2 | ||
| Resolution: | 480 TVL | ||
| S/N Ratio: | 52dB ( MIN ) / 60dB ( TYP ) (AGC OFF) | ||
| Auto iris: | A.E.S. / Manu: 8 Step | ||
| Lens: | 22X optical ZOOM LENS ,F1.6~3.8,f=4~88mm | ||
| A.E.S.: | 1/60~1/100,000 sec. | 1/50~1/100,000 sec. | |
| Zoom: | 220X (22X Optical 10X Digital) | ||
| Focus: | Auto / Manual | ||
| Position: | 64 Position (Zoom. Focus) | ||
| Video Output: | 1.0V p-p composite video at 75 ohm | ||
| Gamma Correction: | 0.45 | ||
| Gain Control | AGC (18dB max) | ||
| White Balance: | ATW / AWC / FIX | ||
| White Balance Range: | ATW ( 3200---10000 ºK ) / AWB (Auto White Balance) / FIX( 3200 ºK ) | ||
| B.L.C. Function: | Super BLC,48 zone BLC | ||
| Image Negative: | Select by OSD Menu | ||
| Cross Line: | On/Off Select by OSD Menu | ||
| Freeze Function: | Alarm In Trigger Or Select By OSD | ||
| Control Function: | Dry Switch, RS-232C(Drive Option), OSD Control | ||
| Operation Temperature: | -10¡æ TO 50¡æ | ||
| Operation Humidity: | within 85©‡RH | ||
| Power Source: | DC 12V¡À1V / 3.6W (Max) | ||
