Panasonic WV-CW504S Super Dynamic 5 Vandal-Resistant Day/Night Fixed Dome Camera



  • print

Panasonic WV-CW504S Super Dynamic 5 Vandal-Resistant Day/Night Fixed Dome Camera


-- sales from skycneye.com

Article Rating:

Condition:New
Model:WV-CW504S


Usually Ships in 3-5 days

Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days

Product Details

Product Highlights:

*  Super Dynamic 5 Technology
*  1/3" Interline CCD Sensor
*  Sensitivity of 0.01 lx (B&W) at F1.4
*  650 TVL Resolution
*  Auto Back Focus / Adaptive Black Stretch
*  3.8 to 8mm Varifocal Auto-Iris Lens
*  Intelligent-Video Motion Detection
*  Adaptive Digital Noise Reduction
*  IP66-Rated / For Indoor & Outdoor Use

The Panasonic Super Dynamic 5 Vandal-Resistant Day/Night Fixed Dome Camera (NTSC) offers excellent imagery at a resolution of 650 TVL, thanks to the Super Dynamic 5 technology.

The camera operates well even in low-light conditions with a minimum illumination of 0.1 lux (color) and 0.01 lux (B&W) at F/1.4 (wide). Intelligent-Video Motion Detection allows object and scene change detection when the lens is covered, spray painted, removed or defocused. In addition, the Auto Back Focus adjusts the position of the CCD sensor to offer stable focus in both color and B&W modes

Enabled with Adaptive Digital Noise Reduction (2D and 3D-DNR), the camera removes signals that could result in grainy images. Adaptive Black Stretch technology increases the visibility of subjects in dark areas of a video scene without degrading image quality in the brighter areas. 3D color conversion function produces amazing natural color images even in low color temperatures. Furthermore, the Image Stabilizer function produces blur-free images even when the camera is subjected to vibrations caused by wind or from vehicles passing in close proximity.

With an IP66 rating, the camera stays protected against dust and water and is suitable for outdoor installations.The standard unit comes with a clear dome and surface mount.

*  NTSC format videos of resolutions up to 650 TVL
*  Super Dynamic 5 delivers brilliant images thanks to fusion of Super Dynamic, Adaptive Black Stretch, and intelligent-Video Motion Detection technology
*  i-VMD (intelligent-Video Motion Detection) for object and scene change detection when the lens is covered, spray painted, removed or defocused
*  Auto Back Focus adjusts the position of the CCD sensor to offer stable focus in both color and B&W modes
*  Adaptive Black Stretch technology increases the visibility of subjects in dark areas of a video scene without degrading image quality in the brighter areas.
*  High sensitivity with Day & Night (Electrical) function: 0.1 lux (color), 0.01 lux (B&W) at F1.4 allows excellent imagery during day and night
*  3D color conversion function for natural color reproduction even in lower color temperature
*  Industrial grade pan/tilt mechanism provides high reliability
*  3-way hinge (horizontal, vertical and swivel rotation) for easy installation
*  Integration of 2D and 3D-DNR (noise reduction) delivers clear images by removing signals that could result in video noise (grainy images)
*  Dehumidification device allows use in various weather conditions
*  Available mounting options : Flush mount (F type), Surface mount (S type), Embedded ceiling mount (with optional WV-Q169)
*  IP66-rated water and dust-resistant housing
*  IEC 60068-2-75 standard ensures protection against impact

Specifications:

Camera
*  Image Sensor:  1/3" interline transfer CCD
*  Effective Pixels:  976 (H) x 494 (V)
*  Scanning Mode:  2:1 interlace scan
*  Scanning Area:  4.8 x 3.6 mm
*  Scanning Frequency:  Horizontal: 15.734 kHz
                        Vertical: 59.94 Hz
*  Scanning (lines/fields/frames):  525 lines
*  Horizontal Resolution:  Color mode: 650 TVL
                 B&W mode: 700 TVL
*  Minimum Illumination:  Color: 0.1 lux (SENS UP: OFF), 0.003 lux*2 (SENS UP: 32x) at F1.4
                         B&W: 0.01 lux (SENS UP: OFF), 0.0003 lux*2 (SENS UP: 32x) at F1.4
*  Signal-to-Noise Ratio:  50 dB (AGC Off, Weight On)
*  White Balance:  ATW1 (2,700 tp 6,000 K), ATW2 (2,000 to 6,000 K), or AWC (2,000 to 10,000 K)
*  Light Control:  ALC / ALC+
*  Automatic Gain Control:  On (high / mid / low), Off
*  Super Dynamic 5:  On / On (i-VMD) / Off (with BLC masking 8 x 6 areas)
*  Dynamic Range:  52 dB typical (Super Dynamic 5 On)
*  Electronic Shutter:  OFF (1/60), 1/100, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 s
*  Electronic Sensitivity UP:  Off / Auto (2, 4, 6, 10, 16, 32x)
*  Fix (2, 4, 6, 10, 16, 32x)
*  Digital Noise Reduction (DNR):  High / Low
*  Black and White Mode:  Mode: Auto 1 / Auto 2 / On / Off
*  Digital Zoom:  On (up to 2x) / Off
*  Scene File:  2 patterns
*  i-VMD:  Video Motion Detection, Object Detection (Removal and Left Behind), Scene Change Detection
*  Privacy Zone:  On (Gray / Mosaic) / Off
*  Auto Image Stabilizer:  On / Off
*  Camera Title (OSD):  Up to 16 characters
*  Lens Mount:  CS-mount
*  Back Focus Adjustment:  ABF (Auto / Preset / Fix), Manual-Adj
*  Synchronization:  Internal (INT), Multiplexed Vertical Drive (VD2), Line-Lock (LL)

Lens
*  Focal Length:  3.8 to 8.0 mm, 2x varifocal
*  Angular Field of View:  H: 35.6 (tele) to 73.6¡ã (wide)
                         V: 26.6 (tele) to 53.4¡ã (wide)
*  Maximum Aperture Ratio:  1 : 1.4 (wide) to 1 : 1.8 (tele)
*  Focusing Range:  3.9' (1.2 m) to ¡Þ
*  Lens ALC Drive:  DC

Pan/Tilt
*  Panning Range:  ¡À 170¡ã
*  Tilting Range:  ¡À 75¡ã
*  Azimuth:  ¡À 100¡ã

Input / Output
*  Video Output:  1.0 V (P-P) / NTSC composite 75 ¦¸ / BNC Connector
        Multiplexed VD2 and control data capable
*  Monitor Output:  1.0 V [P-P] / NTSC composite 75 ¦¸ / RCA Jack

General
*  Setup Method:  OSD setup menu
*  Language: English, Russian (For setup menu and camera title), German, French, Italian, Spanish (For setup menu), Japanese (Only for camera title. Setup menu is in English.)
*  Safety/EMC Standard:  UL (UL60065), FCC (Part15 ClassA), C-UL (CAN/CSA C22.2 No.60065), DOC (ICES003 ClassA)
*  Power Source and Consumption:  24 VAC 60 Hz, 3.4 W, 14 W*3 12 V DC, 280 mA*4 1
*  Ambient Operating Temperature:  14 to 122¡ãF (-10 to +50¡ãC)
                 -22 to 122¡ãF (-30 to +50¡ãC) *3 2
*  Ambient Operating Humidity:  90 % or less (without condensation)
*  Dehumidification Device : Yes
*  Water and Dust Resistance:  IP66, IEC60529 measurement standard compatible
*  Impact Protection:  IEC 60068-2-75 test Eh, 50J
*  Dimensions:  ø x H : 6.43 x 5.75" (164 x 146 mm)
*  Base Cover (W) : 7.56" (191.5 mm)
*  Weight:  3.74 lb (1.70 kg)
