Sony XC-ES50 1/2 type B/W Analog Camera EIA Industrial Camera



  • print

Sony XC-ES50 1/2 type B/W Analog Camera EIA Industrial Camera


-- sales from skycneye.com

Article Rating:

Condition:New
Model:XC-ES50


Usually Ships in 3-5 days

Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days

Product Details

Easy to install and ideal for image processing and machine vision applications, Sony's XC-ES50 1/2 type B/W Analog Camera (EIA) is part of Sony's new standard of analog B/W video cameras. This cameras features the same CCD technology and improved specifications that are incorporated in the XC-ST70/50/30 series (e.g., simplified and flexible trigger, excellent vibration and shock characteristics) but in an even smaller and lighter package. The camera incorporates the latest Interline Transfer (IT) CCD with HAD technology providing 768 (H) x 494 (V) effective picture elements and features a C-mount type lens mount. With dimensions of 29 (W) x 29 (H) x 32( D) mm and weighing only 50 grams, this camera works great in space-limited and remote head applications.

XCES50 FEATURES:
*  High sensitivity using the 1/2" CCD with HAD technology
*  All controls outside the camera
*  Simplified and flexible trigger
*  Smallest and lightest, one piece analog B/W video camera offered by Sony
*  Excellent vibration and shock characteristics (10G / 70G)

XC-ES50 SPECIFICATIONS:
*  Image Device 1/2" Interline Transfer CCD
*  Signal System EIA Standard
*  Effective Picture Elements 768 (H) x 494 (V)
*  Horizontal Frequency 15.734 kHz
*  Vertical Frequency 59.94 Hz
*  Cell Size 8.4 x 9.8 ¦Ìm
*  Lens Mount C Mount
*  Flange Back 17.526 mm
*  Sync System Internal/External (auto)
*  External Sync System HD / VD (2~5 Vp-p)
*  External Sync Frequency + / - 1%
*  Jitter Less than + / - 50 nsec
*  Scanning System 2:1 Interlaced
*  Video Output 1.0 Vp-p, negative, 75ohms unbalanced
*  Horizontal Resolution 570 TV Lines
*  Minimum Illumination 0.3 lx
*  S/N Ratio 60 dB
*  Gain AGC (0-18 dB) / Manual (0-18 dB) selectable
*  Gamma ON / OFF
*  External Trigger Shutter 1/4 ~ 1/10,000 S
*  Normal Shutter 1/100 ~ 1/10,000 S
*  Power Requirements DC-12V (+9 ~ 16V)
*  Power Consumption 1.6W
*  Dimensions 29 (W) x 29 (H) x 32 (D) mm / 1- 3/16 x 1-3/16 x 1-5/16 inches
*  Mass 50 g (2 oz.)
*  Operation Temperature/Moisture -10 ~ +50deg C / 20 ~ 80%
*  Storage Temperature/Moisture -20 ~ +60deg C / 20 ~ 95%
*  Vibration 10 G (20 ~ 200 Hz)
*  Shock Resistance 70 G
*  Regulations UL 1492, FCC Class A Digital Device (EN50081-2 + EN50082-2), AS4251.1 + AS4252.2
