Condition:New
Model:SNC-DH180
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
The Sony SNC-DH180 is a dual-stream 720p HD Mini Dome network camera with IR Illuminator and View-DR. The vandal-resistant, wide dynamic range camera is designed with a built-in infrared (IR) illuminators.
* "Exmor" CMOS 720p HD Resolution supporting H.264 with 30fps
* View-DR (visibility enhanced wide dynamic range)
* XDNR (Excellent Dynamic Noise Reduction)
* Easy focus function
* DEPA Advanced (Basic Analytics within Camera)
* ONVIF Compliant
Specifications:
| Image | |
| Image Size | Max. image size 1280 x 1024 |
| Maximum Frame Rate | H.264: 20fps (1280 x 1024)/30 fps (1280 x 720) MPEG-4: 25fps (1280 x 1024)/30 fps (1280 x 720) JPEG: 30fps (1280 x 1024)/30 fps (1280 x 720) |
| Camera | |
| Minimum Object Distance | 300 mm |
| Electronic Shutter | 1s to 1/10000s |
| Gain | Auto (3 levels) |
| Exposure Control | Auto, EV Compensation, Auto Slow Shutter |
| Minimum Illumination | 0.2 lx (Color), 0 lx (B/W) - IR ON (F1.2 / View-DR Off/VE Off / AGC High(48dB max.) / XDNR Middle / 50IRE [IP]) |
| White Balance Mode | Auto (ATW, ATW-PRO), Preset, One-push WB, Manual |
| Image Device | 1/3 type progressive scan "Exmor" CMOS sensor |
| F-Number | F1.2 (wide), F2.1 (tele) |
| Horizontal Viewing Angle | 85.4 to 31.2 degrees |
| Lens Type | Vari-focal lens |
| Focal Length | f=3.1 to 8.9mm |
| Day/Night function | Yes |
| Horizontal Resolution | 600TVL |
| Compression Format | H.264, MPEG-4, JPEG |
| Camera Type | Mini Dome, IP66, IK10 |
| Wide-D | Yes (View-DR: 125dB) |
| Zoom Ratio | Optical 2.9X (x2 Digital Zoom) |
| Number of Effective Pixels | 1.4 Megapixel (1329 x 1049) |
| Other Functions | IR Illuminators (Wave Length: 850nm [Typical], IR LED: 21pcs) |
| Analog Video Output | |
| S/N Ratio | more than 50 dB |
| Signal System | NTSC/PAL |
| Audio | |
| Audio Compression | G.711/G.726 |
| Interface | |
| Analog Video Ouput | BNC x 1, RCA x 1 |
| I/O Port | Sensor in x 1; Alarm out x 2 |
| External Microphone Input | Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power |
| Audio Line Output | Mini-jack (Monaural), Max output level: 1 Vrms |
| Network | 10BASE-T/100BASE-TX (RJ-45) |
| General | |
| Weight | Approx. 1380 g (3 lb 1 oz) |
| Power Requirements | PoE, AC24V, DC12V |
| Dimensions (W x H x D) | 166 x 119 mm (6 5/8 x 4 3/4 inches) |
| Power Consumption | 28 W max. |
| Operating Temperature | AC24V/DC12V: -30 to 50 ˇăC PoE (IEEE802.3af): -10 to 50 ˇăC |
| Storage Temperature | -20 to 60 ˇăC |
| Supplied Accessories | CD-ROM (User's Guide, SNC Toolbox), Installation manual, Wire rope, Bracket, BNC cable, I/O cable, Audio cable, M4 shoulder screw, M4 screw x 4, Flyee, L-wranch, B&P Warranty Booklet, Template |
| Network | |
| Protocols | IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) |
| Number of Clients | 10 |
| Authentications | IEEE802.1X |
| System Requirements | |
| Operating System | Windows XP, Windows Vista |
| Processor | Intel Core2 Duo 2 GHz or higher |
| Memory | 1GB or more |
| Web Browser | Microsoft Internet Explorer Ver 6.0 or 7.0 |
