Condition:New
Model:Watec W-01CDB3
DC12V
Vehicle Industrial Camera
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
Watec sets high standards for all their CCTV products, and the Watec W-01CDB3 board camera is no exception. With its ultra compact form and in the absence of an enclosure, the W-01CDB3 is the ideal camera for professional covert and custom video installations. Despite being small, Watec was able to incorporate into it a wealth of electronic picture controls including an advanced shutter speed, white balance and AGC. These will assist the camera in maintaining optimum image quality in a variety of lighting and scene situations. You'll also appreciate the camera's CS lens mount, so you can easily pair it with industry standard CCTV lenses.
Watec W-01CDB3 board camera Features:
* Ultra compact, enclosure-free board camera, suitable for covert and custom video applications
* Excellent picture quality with 1/3" CCD and 450 TVL of resolution
* Good low light performance with 1.5 low lux rating
* CS lens mount, compatible with industry standard CCTV lenses
* High resolution;
* Automatic white balance;
* DC12V;
* Electronic iris, electronic shutter;
* WB;
* AGC;
* Video amplitude switch;
* CS lens mount;
* Video / DC auto iris.
Watec W-01CDB3 board camera Specifications:
| Model | WAT-01CDB3(NTSC) | WAT-01CDB3(PAL) | |
| Image Sensor | 1/3" CCD | ||
| total pixels | 811(H)*508(V) | 795(H)*595(V) | |
| Effective Pixels | 768(H)*494(V) | 752(H)*582(V) | |
| Pixel Size | 6.4um(H)*7.5um(V) | 6.5um(H)*6.3um(V) | |
| imaging system | Ye, Cy, Mg, and G complementary color mosaic filters on chip | ||
| Synchronization mode | internal synchronization | ||
| Scanning system | 2:1 interlaced scanning | ||
| video output | synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance | ||
| resolution ratio(H) | More than 450 TVL(Center) | ||
| minimum illumination | 1.5lx. F1.2 | ||
| S/N | More than 50dB(AGC=3dB,¦Ã= 1.0) | ||
| AE Mode | Fixed | 1/60-1/100 sec. | 1/50-1/120 sec. |
| 1/250,1/500,1/1000,1/2000,1/5000,1/10000,1/20000,1/50000 sec. | |||
| E1 | 1/60-1/100000 sec. | 1/50-1/100000 sec. | |
| WB | ATW, Preset(3200K, 5100K,8200K) | ||
| automatic gain control | 3-24dB | ||
| Gamma Features : | ¦Ã¨P0.45 | ||
| lens | Video /DC | ||
| Image Level | 100IRE / 75IRE | ||
| Mirror image | On/Off | ||
| Power voltage | DC + 12V¡À10% | ||
| power consumption | 1.2W(100mA) | ||
| Operating Temperature | -10 - +40¡æ(Frost-free knot) | ||
| Storage Temperature | -30 - +70¡æ(Frost-free knot) | ||
| Work /Storage humidity | Lower than 95£¥RH | ||
| Mount | CS | ||
| Weight | About 35G | ||
