Condition:New
Model:Watec WAT-240F
Horizontal Resolution : 480TVL
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
Watec WAT-240F is a compact color camera which has flexible arm type and electronic iris. This compmact color camera ensures white balance control and back light compensation.
Watec WAT-240F Features:
* Watec WAT-240F Color Mini Camera
* Ultra-small cylindrical shape,
* Resolution 480Tvl,
* WAT-AVM by the controller to adjust the electronic shutter, gain, white balance and many other parameters,
* Focal length lens can be equipped with a variety of .
* Flexible-arm type
* Electronic iris
* White balance control
* Back light compensation
Watec WAT-240F Specifications:
| Model | WAT-240F |
| image sensor | 1/4" CCD |
| Sensing area(pixel) | P290K |
| Synchronizing System | Internal Synchronization |
| Scanning system | 2:1 |
| video output | 1Vpp-75¦¸ |
| Resolution (horizontal) | 350TVL |
| Minimum illumination | 0.4Lux F2.0£¨AGC High£© |
| Gain control | Automatic gain control(dB) ON=10~22 |
| S/N ratio | 46dB |
| gray properties | ¦Ã¨P0.45/1.0 |
| BLC | ON/OFF |
| Auto electronic shutter EI:OFF | 1/50~1/100,000 sec. EI:FL 1/120~1/100,000 sec. |
| MES | (S)OFF(1/50),1/250,1/500,1/1000,1/2000,1/4000,1/10,000 |
| WB | AUTO /Fixed /3200K£¬4200K£¬5100K£¬6300K |
| Auto Iris Lens | VIDEO/DC |
| Mount | CS |
| Working Voltage | DC+10V~15V |
| working current (mA) | 160 |
| Storage Temperature (¡æ ) | -30~+70 |
| Operating Temperature (¡æ ) | -10~+40 |
| Size W¡ÁH¡ÁL(mm) | §¶18¡Á44+Lens |
| Weight(G) | 25 |
