Intelligent IR Illumination 120M Middle Speed Dome Camera

  • print

Intelligent IR Illumination 120M Middle Speed Dome Camera

-- sales from skycneye.com

Article Rating:


Usually Ships in 3-5 days

Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days

Product Details


* PWM function,intelligent IR illumination & power consumption is variable,dependant the zoom factor
* IR distance 120M; Multiple languages for OSD menu, English, Spanish etc.;
* Support ambient light detection,IR Illumination On 1-15 grade selectable;
* Dome ID, baud rate, communication protocol can be set via the controller;
* Supported Protocols : Pelco-D/P; Others on special request;
* 7",Total metal body construction, waterproof IP 66;
* Optional IP module (built in provision);
* Optional , 4 Alarm inputs and 2 alarm outputs.

Horizontal Rotation Speed 145/s
Tilt Rotation Speed 30/s
Horizontal Rotation Range 360
Tilt Rotation Range 90
Auto Flip Horizontal 180, Vertical 180
Auto control IR LED PWM
A-B Scan User programmable
A-B Scan Speed 0-64 levels adjustable
Dwell Preset 2-60s interval adjustable
Preset Points 220
Go to Preset Speed 01-64 levels adjustable
Guard Tours 3 groups
Guard Points Max.16 points, dwell time user selectable
Home Pos Time 0-60 mins adjustable
Communication Protocol Pelco-D,Pelco-P
Communication RS485 Bus
Baud Rate 1200/2400/4800/9600bps
Operating Temperature Indoor:0~ +40 Outdoor: -40~ +60
Operating humidity 95% Non Condensing
Heater & Blower Auto temperature control
Power AC/DC15-28V 3A (standard power: AC24V3A)
IR Illumination Distance 120M
Power Consumption 20W
Lightning protection transient voltage 3000V
Compatible camara SONY,LG,CNB,SAMSUMG,etc.
LED Angle of Illumination Ø16=13
