Watec WAT-525EX CCIR 1/2 550TVL High Sensitivity & External Synch Monochrome Camera

The Watec WAT-WAT-525EX 1/2" 550TVL High Sensitivity & External Synch Monochrome Camera (CCIR) offers high sensitivity and resolution in an ultra compact size camera (4.6 oz/ 2.1" in length).  A variety of internal controls are included to ensure image quality in various lighting environments, making it ideal for security and machine vision applications.

Features:

*   1/2" Interline transfer CCD Image sensor
*   CCIR Signal System
*   High Resolution: 550 TVL
*   Manual and electronic image controls
*   Super low light sensitivity 0.002 Lux
*   Internal sync. / external sync.(C. video, C. sync.)
*   Manual gain control
*   AGC
*   Shutter speed control (10 steps)
*   Video/DC iris auto-select
*   Flickerless mode
*   Back light compensation
*   Gamma correction
*   Iris level control
*   CS lens mount

Specifications:

*   Model: WAT-525EX (EIA/CCIR)

*   Pick-up element: 1/2inch interline transfer CCD image sensor

*   Number of total pixels: 811(H) x 508(V) (EIA), 795(H) x 596(V) (CCIR)

*   Number of effective pixels: 768(H) x 494(V) (EIA), 752(H) x 582(V) (CCIR)

*   Unit cell size: 8.4um(H) x 9.8um(V) (EIA)

*   8.6um(H) x 8.3um(V) (CCIR)

*   Scanning system: 2:1 interlace

*   Synchronizing system: Internal/External (C. sync/C. video)

*   Sync. signal: 0.2 - 4.0Vp-p

*   Video output: 1.0V p-p 75ohms, unbalanced

*   Resolution (Horizontal): 570TVL(Center)

*   Minimum illumination: 0.002 lx, F1.4

*   Back light compensation:  AGC: ON/OFF, EI: ON/OFF

*   Gamma correction: 0.45/OFF

*   AGC:  ON: 5-32dB(HI), 5-20dB(LO), OFF: 5-32dB(MANUAL)

*   S/N:  ratio 50dB (Gain 5dB)

*   AE mode:  EI(1/60(NTSC) or 1/50(PAL)-100.000 sec.), FL, OFF

*   ES:  1/250, 1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/100000

*   Auto iris:  Video/DC auto-select

*   Power supply:  DC+12V±10%

*   Current:  Max. 150mA

*   Operation temperature:  -10°C - +40°C (w/o condensation)

*   Storage temperature:  -30°C - +70°C (w/o condensation)

*   Weight:  130g

*   Accessories:  WPDC12 (jack plug), Hex. Wrench, AIC-G (iris plug)
